PROTYzer

Elecrolyte Analyzer Series ProMax-5000

PROTYzer Medical System

Type/Category: Bio Chemistry Analyzer

Test speed

70T/H

Medistore is one of the leading Biochemistry Analyzer sellers in Bangladesh. You can choose the best Biochemistry Analyzer according to your requirements. We have a collection of both the Fully Automatic Biochemistry Analyzer and semi-auto Biochemistry Analyzer with a wide variety of world-class renowned brands like BIOMED, CLINDIAG, Diasys, Erba, Evolution 3000,ICUBIO, LABOMED, MyLab, Rayto etc. Medistore is delivering the Biochemistry Analyzer all around Bangladesh. Order Biochemistry Analyzer on our online shop and get home delivery in Dhaka city and get courier delivery from all over Bangladesh. All popular Biochemistry Analyzer brands are available on Medistore. For more details, you may call us at 01405100400

Download PDF

* EMF (energy Matched filter)
* ERA Flow cell with Copper flow cell holder - Auto temperature maintenance
* Aspiration air gap and Auto Empty Function - No more worries on carry over
* Direct Access Key to the test menu
* ALD Function - Ensure extended life for the lamp & power saving
* Incomparable memory

analyzer, BioChemistry, BioChemistry analyzer, Hospital Equpment, Medical Equpment, Meidical Machine, PROTYzer, Semi Auto BioChemistry

Parameter

Incubator: Multifunctional incubator.
Test method: 1 Point end, 2 Point end, kinetics, Fixed-time, Turbidity.
Test mode: Flow cell & Cuvette.
Optics: 8 Standard wavelengths:- 340nm, 405nm, 450nm, 510nm, 546nm, 578nm, 600nm, 630nm. 2 more for optional.
Lamp house: Long-life tungsten halogen lamp, auto-sleep function.
Temperature: 25ËšC, 30ËšC, 37ËšC and incubator unit 37ËšC.
Flow cell capacity & Optical path: 32Âµl, 10mm.
Resolution: 0.0001 Abs.
Photo-metric range: 0.0000-3.3000 Abs.
Display: 7.0â€ TFT LCD with touch screen, 800*480 pixels.
Printer: Build-in thermal printer (30mm printer paper), support external printer.
CPU: ARM Cortex-A8, 800MHz; DDR3 SDRAM: 512MB Flash: 256MB.
Memory: SD card: 8G.
Interface: USBx4, Ethernet portsx1, RS232x1.

Operational Environment: Temperature: 15ËšC ~ 35ËšC, Humidity: 35% ~ 85%.
Power requirement: Wide power supply AC 100-240V, 50/60Hz.
Dimension: 400*300*180mm (L*W*H).

Operation

automatic, automated, POC
